Bag Filter

The bag filter is a device that filters through pressure. When the liquid passes through the inlet of the machine and is filtered by the filter bag, it will effectively filter impurities and obtain high-quality materials.


paint, ink industry.

Advantages of bag filter:

  • small volume
  • easy to use
  • Energy-saving and high efficiency
  • Strong circulation ability












Hot sale Bead mill

Technical Parameter

Bag Filter Parameters

Guidelines For Bag Filter

Which is small size machine, easy-operation, save energy, high efficient, seal-working, suitable multi-function bag filters. Bag filter is a new type of filter system. The inside of the bag filter is supported by a metal mesh basket. The liquid flows in from the inlet and flows out from the outlet after being filtered by the filter bag. The impurities are intercepted in the filter bag and can be used continuously after the filter bag is replaced.

The bag filter is a pressure filter device, which mainly consists of one filter cylinder body, one filter cylinder cover, one quick-opening mechanism, one stainless steel filter bag reinforcing mesh and other main components. The filtrate flows into the filter bag from the side inlet pipe of the filter housing. The filter bag itself is installed in the reinforced mesh basket, and the liquid can obtain qualified filtrate by infiltrating the filter bag of the required fineness grade, and the impurity particles are intercepted by the filter bag. The machine is very convenient to replace the filter bag, and there is basically no material consumption for filtration.

The bag filter has many advantages such as reasonable structure, good sealing performance, strong circulation ability and easy operation. In particular, the probability of side leakage of the filter bag is small, the filtration accuracy can be correctly guaranteed, and the filter bag can be changed quickly, which reduces the operating cost. The inner and outer surfaces of the filter are polished by mechanical sandblasting, which is average and easy to clean. We know that the filtration method adopted by the bag filter is the method of side-in and side-out, or the method of side-in and bottom-out can also be adopted, and the filtered liquid medium is pressed or pumped into the bag filter barrel through the pressure in the pipeline. , the liquid medium to be filtered is filtered by the filter bag supported by the filter blue through the electropolishing punching holes, and the changed solid and liquid respectively reach the result of the liquid medium being filtered.

The structural design of the bag filter is that the top cover and the filter cartridge are sealed and locked by four sets of rocker-type eye bolts, so that the filter can withstand extremely high filtration pressure and water hammer pressure impact. The bag filter is composed of three parts: filter cartridge, filter basket and filter bag. The structure is compact and simple; the liquid to be filtered enters through the inlet of the filter, flows into the filter bag, and flows out from the outlet of the filter after being intercepted by the filter bag. . The inlet and outlet design of the bag filter generally adopts the side-in and bottom-out method, which is convenient for cleaning.

Bag Filter is used in painting, ink industry. If needs more working pics, and videos, welcome to connect with us.
