Horizontal Ribbon Mixer
The horizontal ribbon mixer is driven by the inner and outer diameter screw mounted on the mixing shaft to drive the material in the barrel so that the agitator can turn the material in the barrel in a wide range.
Application:
Coating, Pesticides, veterinary drugs, food, chemicals, biology, aquaculture, ceramics, refractory materials, plastics, compound fertilizers, etc. And also suitable for mixing viscous materials like putty.
Advantages of ribbon mixer：
- High quality
- Easy to use
- Provide customized services according to customer material characteristics
Application
Coating
Cosmetic
Battery
Graphite
Agrochemistry
Adhesives
Hot sale
Guidelines For Ribbon Mixer
The horizontal ribbon mixer is driven by the inner and outer diameter screw mounted on the mixing shaft to drive the material in the barrel so that the agitator can turn the material in the barrel in a wide range.
In the structure of the agitator, the spiral of the horizontal ribbon mixer is designed to be reverse spiral inside and outside, and left and right. When the agitator is working, the inner spiral drives the material near the axis to make the axis rotation, and the axis is pushed from the inside to the two sides.
The outer spiral of the horizontal ribbon mixer drives the material close to the barrel wall to make the axis rotary, and the axial direction is pushed from both sides to the inside so that the material is convectively circulated in the barrel, shearing, and mixing, and the material is mixed in time.
Which suitable for coating, Pesticides, veterinary drugs, food, chemicals, biology, aquaculture, ceramics, refractory materials, plastics, compound fertilizers, etc. And also suitable for mixing viscous materials like putty.
