Double Planetary Mixer: Laboratory & Production
Double Planetary Mixer
There are two types of double planetary mixers produced by FRANLI, which mainly involve two major application fields, one is laboratory research type, and the other is a factory production line, but the functions and application industries of double planetary mixers are the same.
Details of Double Planetary Mixer
- The common agitators include paddle type, twist type, claw type, and frame type.
- good mixing, reaction, kneading, and dissolution functions.
inks, colorants, dyes, coatings, and other industries.
A double planetary mixer is a multi-purpose and high-efficiency equipment with dispersion and mixing. It can be applied to electronic devices, electronic pastes, adhesives, molding glue, silicone weather-resistant adhesives, polyurethane material sealants, anaerobic adhesives, paints, printing inks, color pastes, skin care products, plasters, diagnosis and treatment, electronic devices, Chemical plants, food, decorative building materials, chemical fertilizers, and other fields. Among them, the double planetary mixer is especially suitable for the mixing of viscous raw materials such as sealant and putty powder, to remove the air bubbles generated during mixing. Its production efficiency is the most notable feature, which can reach many times that of ordinary mixing equipment.
Whether it is a laboratory type or a production line equipment, after the double planetary mixer is running, the large planetary frame rotates, pushing the two mixing shafts in the box to rotate accordingly, and running at high speed. At the same time, it rotates around the center line of the barrel section to make the raw materials It is subject to strong cutting and pre-shaping, to achieve the purpose of full dispersion and mixing. There is a row of scrapers on the large planetary frame that rotates together with the large planetary frame, close to the cylinder wall, and carries out continuous scraping and grinding. This operation can scrape all the raw materials on the inner wall of the cylinder so that there is no material on the inner wall of the cylinder.
Production of double planetary mixer
Advantages of double planetary mixer:
Dual planetary mixers have high mixing efficiency and wide application fields are their most significant advantages: generally suitable for mixing low viscosity materials, but generally speaking, general purpose dual planetary mixers can handle 500,000 cups of raw materials, and the specifications of customized models can be Solve the viscosity of 5 million cps or higher, and can easily handle the problem of viscous manufacturing materials.
The operation of the double planetary mixer has a certain degree of convenience and safety, and the raw materials put in are not sticky to the wall, the feeding is neat, and the barrel joints are easy to clean.
Strong non-standard: explosion-proof type, vacuum pump type, heating type, can also be customized according to raw materials.
High level of automation technology: users can choose PLC programming operation to automatically detect and control the ambient temperature and speed in the bar. The rotation and constant speed of the stirring paddle are adjusted by frequency conversion, and different speed ratios can be selected according to different processing techniques and different viscosities.
The double planetary mixer in the laboratory adopts a unique mixing mechanism, the position of the opening bucket is fixed, and the dispersing plate and the stirring paddle of this mixer complete the planetary motion of both self-rotation and uniform rotation, and the speed can be adjusted through the PLC operation panel. speed regulation. The mixer makes the raw materials uniformly stirred in the barrel, and the materials are cut and pre-molded, the raw materials are fully dispersed and mixed, and the mixing dead point is not easy to occur. The scraper of the double planetary mixer in the laboratory rotates around the centerline of the kettle body to scrape off the raw materials adhered to the inner wall of the kettle and mix them again. The sealing performance of the mixer is unique, and it can be pressurized or vacuum-packed to remove air bubbles, etc.
The scraper of the laboratory double planetary mixer rotates around the center line of the kettle body, scraping off the raw materials stuck to the inner wall and participating in the mixing so that the actual effect is more ideal. The kettle body adopts a unique sealing structure, which can be pressurized and vacuum-packed, and has a good air-defoaming effect. The engine block collet can be heated and cooled according to customer needs. The feeding method is a stripping type, the equipment cylinder head can be raised and lowered, and the engine block can be moved freely, so the operation is very convenient. Moreover, the stirring paddle and the scraper can completely get rid of the engine block with the lifting of the load-bearing beam, which is beneficial for cleaning.
As a professional double planetary mixer manufacturer, FRANLI provides a complete set of mature equipment for related machines and production lines for more than 60 countries and thousands of industries in the world, and in Russia, Turkey, Spain, Brazil, Malaysia, Indonesia, and other regions, for Many enterprises have established related production lines.
Welcome to send inquiry to us and let’s make a win win business together !
